Richpeace Automatic Tufting (Bar Tacking) Machine
Speed: 2000RPM
Size: 1200X600mm
Power: 3.5KW
Voltage: 220V/380V
Application: Able to stitch circle or any motif for tufting purpose, suitable for any kinds cushion of chair pad, deck chair, rush cushion, pet mat, furniture etc, and other various inner / outdoor bar tracking automatic production line.
Description
Product Video
Product Introduction
- Working speed: 2000rpm.
- Press-hand is synchronous working with frame, ensure sewing motif high precision (Patent, Inventor).
- No need to fix cushion position, just put in the frame then place directly, easy tto change cushion without stopping machine.
- Quickly changing frame or use modular frame, for change pattern easily.
- Highest sewing speed, just 5 seconds to finish one tacking.
- Template positioning detective function, four design patterns circulate function.
- Bobbin thread counter enable to provide bobbin thread capacity alert by bobbin thread consumption or number of sewing pieces made.
- Sewing head can lift up to 150mm, maximum bar tacking diameter is 50mm.
Special function for sewing bar tacking on a thick mat, sewing area is based on 1200X600mm (according to customer’s requirements can customize). High efficiency, High strength, High difficulty.
Product Parameters
| PRODUCT MODEL | RPAS-BT-1-1200X600-AB-2-LH |
| WORKING AREA (MM) | 1200X600 |
| POWER | 3.5KW |
| VOLTAGE | SINGLE PHASE 220V, THREE PHASE 220V, 380V |
| ATMOSPHERIC PRESSURE | 0.6MPA |
| MAX.SPEED | 2000RPM |
| DIMENSION (LXWXH) (MM) | 3250X2000X1450 |
